Product specifications

Terminal type Iot terminal (optional support for single mode satellite or single mode 4G)

Main engine size 90*90*34.7mm

Satellite frequency band Uplink 1980-2010MHz, downlink 2170-2200MHz

Cellular networks support frequency bands FDDLTE、TDDLTE、TD-SCDMA、UMTS、EVDO、CDMA1x、GSM

SIM card type Satellite: 4FFSIM card; 4G:4FFSIM card

Operating system Linux

Master control platform NXPMCIMX6Y2

Body memory 4GBROM+256RAM

Battery capacity Reserved external interface

Power input DC9V-36V

Antenna gain ≧5dBi

Packing list Host, adapter, Quick guide, antenna

Basic function Tiantong SMS and 4G data automatically report and collect data

Key Reset

T-flash card Support

LED 4 LED two-color indicators

Control Mode Remote + serial control

Information collection Collect sensor information through the external interface and report it to the specified platform through the satellite or ground network

GNSS navigation GPS/BEIDOU

Connector HostUSB interface, can support a variety of interface switching; RJ45; External battery interface; Micro-USB; Serial port

Operating temperature -20℃~55℃

Storage temperature -50℃~70℃
